Name: 24CH PM Fiber Array, High-Density PMFA, Polarization Maintaining FA, Corning PM1550 Fiber Array
Brand: Shenzhen Gracyfiber Technology Co., Ltd.
Availability: InStock

Detail Information

Product Description

Detail Information

Channel Count:

Channel Spacing:

127 μm

Insertion Loss:

≤0.3 DB

Extinction Ratio:

≥18 DB

Highlight:

24CH PM fiber array high-density

Polarization maintaining FA Corning PM1550

High-density PMFA polarization maintaining

Product Description

24CH PM Fiber Array, High-Density PMFA, Polarization Maintaining FA, Corning PM1550 Fiber Array

1. Product Overview

This product is a 24-channel PMFA polarization-maintaining fiber array, using Quartz Glass and Corning PM1550 polarization-maintaining fiber.

2. Core Product Features

Parameters	Unit	Spec.	Value
Channel	/	24	OK
Material	/	Quartz Glass	OK
Channel Spacing	μm	127	OK
Polishing Angle	Degree	0°	OK
Package(L)X(W)X(H)	mm	125.71.5	OK
Insertion Loss	dB	≤0.3







Extinction Ratio	dB	≥18	25







FA PM Fiber Alignment	/	PMII	OK
Connctor PM Fiber Alignment	/	Slow Axis Alignment Key	OK
Fiber Type	/	PM1550(Corning)	OK
Fiber Tube	mm	0.9	OK
Tube Color	/	Blue	OK
Length	m	1±0.1	OK
Connector	/	FC/APC	OK
Operating Temperature (℃)		0～65	OK
Storage Temperature (℃)		-40～85	OK

24-channel PMFA polarization-maintaining fiber array design
127μm channel spacing, 0° polishing angle
Corning PM1550 polarization-maintaining fiber
Insertion loss IL < 0.3dB
Extinction ratio ER ≥ 18dB
FC/APC connector configuration

24CH PM Fiber Array, High-Density PMFA, Polarization Maintaining FA, Corning PM1550 Fiber Array 0

3. Applications

Polarization-maintaining fiber communication systems
Optical module and optical device coupling
Coherent optical communication systems
Fiber optic sensing systems
Laser and modulator coupling
Laboratory optical path testing and R&D platform
