| Model Number: | CWDM-18M271PL0905-55 |
4/8/12/18CH CWDM Mux Demux Module 1260-1620nm 20nm Channel Spacing Fiber Optic WDM Multiplexer Demultiplexer LC/SC/FC for PON CATV Broadband Networks
Gracyfiber Coarse wavelength division multiplexer (CWDM) utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging. It provide low insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path.
| Parameters | Unit | 4CH | 8CH | 12CH | 18CH | |
|---|---|---|---|---|---|---|
| Operating Wavelength | nm | 1260~1620 | ||||
| Channel Space | nm | 20 | ||||
| Center Wavelength | nm | ITU,ITU+1 | ||||
| Center Wavelength Accuracy | nm | ±0.8 | ||||
| Pass band @-0.5dB | nm | ±6.5 | ||||
| Port Insertion Loss | dB | ≤1.2 | ≤2.5 | ≤3.5 | ≤3.8 | |
| Link Loss | dB | ≤2.0 | ≤3.2 | ≤4.0 | ≤4.3 | |
| Isolation (dB) | Adjacent | dB | ≥30 | |||
| Non-adjacent | dB | ≥40 | ||||
| Ripple | dB | ≤0.5 | ||||
| Polarization Dependent Loss | dB | ≤0.2 | ||||
| ITU-T G.694.2 | ||||
|---|---|---|---|---|
| Nominal central wavelengths(nm) | ||||
| 1 | 1270 | 10 | 1450 | |
| 2 | 1290 | 11 | 1470 | |
| 3 | 1310 | 12 | 1490 | |
| 4 | 1330 | 13 | 1510 | |
| 5 | 1350 | 14 | 1530 | |
| 6 | 1370 | 15 | 1550 | |
| 7 | 1390 | 16 | 1570 | |
| 8 | 1410 | 17 | 1590 | |
| 9 | 1430 | 18 | 1610 | |
60*40*11(mm)
100*80*10mm
120*80*18mm
140*115*18mm
| XX | X | XX | XX | XX | XX | - | X | X |
|---|---|---|---|---|---|---|---|---|
| Channel No. | MUX/DEMUX Type | Initial CW | Package Type | Fiber Type | Fiber Length | Input Connector | Output Connector | |
| 04= 02CH | M=Mux | 270= 1270 | SM=65 x45 x11 | 09=0.9mm | 05=0.5m | 0=No | 0=No | |
| Tube | ||||||||
| ………… | D= Demux | … | PS=100x80x10 | … | 1=FC/UPC | 1=FC/UPC | ||
| 08= 08CH | M&D= | 550=1550 | PM=120x80x18 | 10=1m | 2=FC/APC | 2=FC/APC | ||
| Mux&Demux | ||||||||
| 551=1551 | PL=140x115 x18 | 3=SC/UPC | 3=SC/UPC | |||||
| P1=80x58 x8 | 4=SC/APC | 4=SC/APC | ||||||
| X0= Customized | 5=LC/UPC | 5=LC/UPC | ||||||
| SM=65 x45 x11 | 6=LC/APC | 6=LC/APC |
| Part Number | Product Description |
|---|---|
| CWDM-18M271PL0905-55 | CWDM Mux Module 1271~1611nm ,18 Port , |
| ABS box(140*115*18mm), 0.5m with 0.9mm White Tube color, | |
| LC/UPC connectors. |
