12 Channel FWDM Cascaded Module DATA 1260 1620nm OTDR 1650nm Reflect 12F MPO APC Female LC APC for PON FTTx Network
1. Product Overview
The 12×(1×2) FWDM module is used for transmission in the 1260~1620nm data band and reflection in the 1650±10nm OTDR monitoring band, enabling the integration of data service transmission and fiber optic link monitoring.
2. Core Product Features
| Parameters | Specifications | Unit |
|---|---|---|
| Operating Wavelength | 1260-1660 | nm |
| Pass band Wavelength | 1260-1620 | nm |
| Reflect band Wavelength | 1640-1660 | nm |
| Insertion Loss (COM<-->Pass) | ≤1.0 | dB |
| Insertion Loss (COM<-->Reflect) | ≤0.8 | dB |
| Isolation (Pass Channel) | ≥40 | dB |
| Isolation (Reflect Channel) | ≥15 | dB |
| Insertion Loss Temperature Sensitivity | ≤0.5 | dB |
| Wavelength Temperature Shifting | ≤0.002 | nm/°C |
| PDL | ≤0.1 | dB |
| PMD | ≤0.15 | ps |
| Ripple | ≤0.5 | dB |
| Directivity | ≥55 | dB |
| Return Loss (RL) | ≥50 | dB |
| Maximum Power Handling | 500 | mW |
| Operating Temperature | -40~+85 | °C |
| Storage Temperature | -40~+85 | °C |
| Fiber Type | G657A2 | / |
| Tube Type (COM Port) | 0.9mm Blue Loose Tube (Hytrel) | / |
| Tube Type (PASS Port) | 0.9mm White Loose Tube (Hytrel) | / |
| Tube Type (Reflect Port) | 3.0mm Yellow Loose Tube (LSZH) | / |
| Fiber Length (COM Port) | 500±50 | mm |
| Fiber Length (PASS Port) | 500±50 | mm |
| Fiber Length (Reflect Port) | 0.9m±50mm | / |
| Connector (COM & PASS Port) | LC/APC | / |
| Connector (Reflect Port) | 12F MPO/APC(Female) | / |
| Package Dimension (ABS Box) | L100×W80×H10 | mm |
3. Application Scope
