32CH 100GHz DWDM AAWG Module Gaussian C22 C53 Low Insertion Loss Fiber Optic Mux Demux SC APC ABS Box for C Band Optical Network

32CH 100GHz DWDM AAWG Module Gaussian C22 C53 Low Insertion Loss Fiber Optic Mux Demux SC APC ABS Box for C Band Optical Network

Model Number: 952005101-02
Detail Information
Product Description
Detail Information
Channel Count:
32CH
Channel Spacing:
100GHz
Insertion Loss:
≤3.5 DB
Operating Temperature:
-5~+65°C
Highlight:

32CH DWDM Mux Demux module

,

100GHz Gaussian DWDM AAWG

,

SC APC ABS fiber optic Mux

Product Description
32CH 100GHz DWDM AAWG Module Gaussian C22 C53 Low Insertion Loss Fiber Optic Mux Demux SC APC ABS Box for C Band Optical Network
1. Product Overview

This 32-channel 100G DWDM AAWG module (part number: 109-01778) utilizes Gaussian chip technology, precisely covering the C22-C53 operating frequency band.

2. Product Features
Parameters Unit 40CH 100G DWDM AAWG Module
ChannelCH40 (C19~C58)
Chip typeGaussian
Operating wavelengthnm1500~1570
Channel SpacingGHz100
Channel Pass bandnmITU±0.11
Insertion LossdB≤3.5
Bandwidth@1dBnm≥0.2
Bandwidth@3dBnm≥0.4
Adjacent IsolationdB≥26
Non-adjacent IsolationdB≥30
Non-adjacent CrosstalkdB≥21
Return LossdB≥40
DirectivitydB≥50
Channel UniformitydB≤1.5
RippledB≤1.5
Fiber typecmG657A1 of 0.9mm loose tube
ConnectorSC/APC
Chromatic Dispersionps/nm±20
Operating Temperature°C-5~+65
Packaging dimensionmmL120*W80*H18
  • Gaussian 32-Channel DWDM (C22-C53)
  • 100GHz Standard ITU Mesh Spacing
  • Extremely Low Insertion Loss (≤ 3.5 dB)
  • High Isolation Between Adjacent and Non-Adjacent Channels (≥ 26 dB / ≥ 30 dB)
  • 0.9mm Loose Tube Fiber Optic Pigtails (Incoming/Outgoing Optical Length 100~110cm)
  • Independent Numbering Tubes (for easy identification and maintenance of high-density cabling)
  • SC/APC High-Standard Connectors
  • 120*80*18mm Compact ABS Enclosure
  • Neutral Unbranded Packaging (OEM Friendly)
3. Applications
  • High-Capacity DWDM Transmission System Expansion
  • Long-haul Backbone and Metropolitan Area Network (MAN) Backbone Nodes
  • High-Density Data Center Interconnect (DCI)
  • Optical Add-Drop Multiplexer (OADM) Networking
  • International System Integration and OEM Projects
