1. Features
Delivers ultra-low insertion loss combined with exceptionally high return loss for optimal signal integrity.
Guarantees a high extinction ratio (ER) to ensure superior polarization maintenance.
Engineered for high stability and reliability in demanding optical environments.
Features precise slow-axis key orientation with strict axis alignment tolerances of ±3 degrees.
2. Applications
High-power fiber laser systems and component integration.
Optical fiber amplifiers and specialized routing modules.
Precision testing instruments and measurement equipment.
Advanced optics laboratory research and development.
3. Specifications
Operating Wavelengths: Broad support covering 850 nm, 980 nm, 1064 nm, 1310 nm, 1480 nm, and 1550 nm.
Optical Performance: Insertion loss as low as ≤0.3 dB and extinction ratio up to ≥23 dB (for 1310~1550nm models at 23°C).
Return Loss: Excellent reflectance control achieving ≥50 dB for UPC connectors and ≥55 dB for APC connectors.
Fiber Type & Length: Built with premium PM850, PM980, PM1310, or PM1550 Panda fiber, available in standard 1m lengths or customized.
Connector Options: Highly customizable with FC/UPC, SC/UPC, LC/UPC, FC/APC, and SC/APC interfaces.
