The 100 GHz DWDM 4CH Demux Module is a passive wavelength-separation device configured to divide a composite optical signal into four DWDM channels: C59, C47, C34, and C22. It uses SMF-28e fiber, FC/APC interfaces, 2.0 mm yellow protective tubing, and a 100 * 80 * 10 mm ABS box package. The specified insertion loss is no more than 1.8 dB, while the pigtail length is controlled at 1.00 ± 0.05 m.
| Performance Specifications | Unit | Value 1 | Value 2 |
|---|---|---|---|
| Channels | CH | 4 | 4 |
| Operating Wavelength | nm | C22/C34/C47/C59 | C31/C34/C36/C38 |
| Channel Spacing | GHz | 100G | 200G |
| Transmission Band | nm | ITU ±0.11 | ITU ±0.22 |
| DWDM Insertion Loss | dB | ≤1.8 | ≤1.8 |
| Min. Extinction Ratio at 23°C | dB | / | ≥16 |
| Isolation – Adjacent | dB | ≥28 | ≥28 |
| Isolation – Non-adjacent | dB | ≥40 | ≥40 |
| Ripple | dB | ≤0.5 | ≤0.5 |
| Directivity | dB | ≥50 | ≥50 |
| Return Loss | dB | ≥45 | ≥45 |
| Polarization Dependent Loss | dB | <0.2 | <0.2 |
| Work Axis | / | / | Slow Axis Alignment |
| Operating Temperature | °C | -5~65 | -5~65 |
| Storage Temperature | °C | -40~85 | -40~85 |
| Max. Optical Power | mW | 300 | 300 |
| Package Size (L*W*D) | mm | 100*80*10 | 100*80*10 |
| Fiber Length | m | 1.0±0.05 | 1.0±0.05 |
| Fiber Type | / | 2.0 mm Protective Cover (Yellow) | 2.0 mm Protective Cover (Blue) |
| Fiber Type | / | SMF-28e | PM1550 Fiber |
| Connector | / | FC/APC | FC/APC |
Optical performance can be tested according to the agreed specification. Key parameters are verified before shipment, including the channel configuration and insertion loss when included in the approved inspection criteria. Test reports can be provided upon request. Customized inspection requirements can be discussed to define the required test items, acceptance limits, port identification, and reporting format.
![]()
It separates a composite DWDM optical signal into four individual wavelength channels: C59, C47, C34, and C22.
Not necessarily. For this passive DWDM product, it most likely refers to a 100 GHz channel grid. The formal designation should be confirmed before publication.
No. C59, C47, C34, and C22 form a non-consecutive channel plan intended for a specific wavelength-routing requirement.
The specified fiber type is SMF-28e single-mode fiber.
The current configuration specifies FC/APC connectors. The connector assignment for the common port and each channel port should be confirmed in the product drawing.
The module is housed in a 100 * 80 * 10 mm ABS box with 2.0 mm yellow protective tubing on the fiber pigtails.
Any alternative channel plan, connector type, fiber length, tubing, or housing requirement should be submitted for engineering review before quotation.
Please provide the operating wavelength or ITU channel plan, channel count, fiber type, connector type, fiber length, package requirement, target optical specifications, port definition, and estimated quantity.
For a technical review or quotation, please provide the required operating wavelength or ITU channel plan, channel count, fiber type, connector type, fiber length, package requirement, target optical specifications, and estimated quantity. Please also identify the common port, individual channel ports, required pigtail lengths, and any test-report requirements.
