100 GHz DWDM 4CH Mux Module with C59/C47/C34/C22 Channels for Optical Transport,Passive Optical Components

The 100 GHz DWDM 4CH Mux Module is a passive wavelength multiplexer designed to combine four DWDM channels—C59, C47, C34, and C22—onto a shared optical path. It is built with SMF-28e fiber, FC/APC connectors, 2.0 mm yellow protective tubing, and a 100 * 80 * 10 mm ABS housing.

• Four specified DWDM channels—C59, C47, C34, and C22 — supports wavelength consolidation for a project-specific optical channel plan.
• Insertion loss of ≤1.8 dB — helps control optical power loss between the channel ports and the common optical path.
• SMF-28e fiber pigtails — support integration with standard single-mode optical transmission assemblies.
• FC/APC connector configuration — helps reduce connector-interface reflection in systems using angled physical-contact ports.
• 1.00 ± 0.05 m fiber length — provides a defined pigtail length for equipment routing and installation.
• 2.0 mm yellow protective tubing — supports mechanical protection and visual identification of the fiber pigtails.
• 100 * 80 * 10 mm ABS housing — provides a box-type format for installation within optical equipment or subsystem enclosures.
• −5°C to +65°C operating range — defines the specified environmental temperature range for system integration.

• DWDM transmission networks
• Metro optical transport systems
• Access network wavelength multiplexing
• Data center interconnect links
• Point-to-point fiber capacity expansion
• DWDM equipment and line-card integration
• Optical wavelength-management assemblies
• Optical test and monitoring systems

Optical performance can be tested according to the agreed specification. Key parameters are verified before shipment, including the channel configuration and insertion loss when included in the approved inspection criteria. Test reports can be provided upon request. Customized inspection requirements can be discussed before order confirmation to define the required test items, acceptance limits, port identification, and reporting format.

• Defined channel configuration: The C59, C47, C34, and C22 channel plan supports integration into applications requiring a specific non-consecutive wavelength combination.
• System-oriented package format: The ABS box, protected pigtails, and FC/APC interfaces support module-level installation within optical equipment.
• Parameter review before production: Channel selection, fiber routing, connector configuration, package requirements, and optical criteria can be checked against the system design.
• Testing documentation: Agreed optical parameters can be recorded in a test report upon request.
• Evaluation and supply planning: The configuration can be reviewed for initial sample or small-batch verification and subsequent quantity requirements, subject to engineering and commercial confirmation.

It combines the four specified DWDM channels—C59, C47, C34, and C22—onto a common optical path for transmission through a single fiber link.

Not necessarily. In this product context, it likely refers to a 100 GHz DWDM channel grid. The formal product designation should be confirmed before publication.

No. They form a non-consecutive channel plan. This configuration may be used when the system requires specifically assigned wavelengths rather than adjacent channels.

The specified fiber type is SMF-28e single-mode fiber. The fiber supplier and complete fiber specification have not been provided.

The current configuration specifies FC/APC connectors. The number of connectorized ports and the connector arrangement for each channel and common port should be defined in the approved drawing.

The module uses a 100 * 80 * 10 mm ABS box-type housing with 2.0 mm yellow protective tubing on the fiber pigtails.

Alternative channel plans, fiber lengths, connectors, tubing, and package requirements should be submitted for engineering evaluation. Availability should be confirmed before quotation.

Please provide the operating wavelength or ITU channel plan, channel count, Mux or Demux function, fiber type, connector type, fiber length, package requirement, target optical specifications, port definition, and estimated quantity.

For a technical review or quotation, please provide the required operating wavelength or ITU channel plan, channel count, fiber type, connector type, fiber length, package requirement, target optical specifications, and estimated quantity. Please also specify whether the required device is a Mux, Demux, or bidirectional configuration, together with the channel-port and common-port definitions.
