2CH SMFA Fiber Array，2CH Single Mode Fiber Array，2CH MFD Conversion Fiber Array | 250μm Pitch, 0° Angle | Nufern UHNA7 to G657A2 Spliced | FC/APC, Low IL <0.3dB | Optical Transceiver FA

Model Number:	910001702-29

Detail Information

Product Description

Detail Information

Document:

Channel Spacing:

250μm

Polishing Angle:

Insertion Loss:

≤0.3dB

Fiber Type:

Nufern UHNA7+G657A2

Highlight:

2CH SMFA fiber array 250μm pitch

2CH MFD conversion fiber array low IL

single mode fiber array FC/APC

Product Description

2-Channel Single Mode Fiber Array (SM FA) | 250μm Pitch, Quartz Glass, 0° Flat Polished | UHNA7 & G657A2 Spliced Fiber, FC/APC Connector

Product Overview

The 2-channel single-mode fiber array (2CH SMFA) is designed for high-precision beam coupling and high-density photonic integration.

Features

Parameters	Unit	Spec.	Value
Channel	/	2	OK
Material	/	Quartz Glass	OK
Channel Spacing	μm	250	OK
Polishing Angle	Degree	A0°	OK
Package(L)X(W)X(H)	mm	102.52.5	OK
Insertion Loss	dB	≤0.3	0.15



Fiber Type	/	Nufern UHNA7+G657A2	OK
Length	m	1±0.1	OK
Connector	/	FC/APC	OK
Operating Temperature (℃)		0～65	OK
Storage Temperature (℃)		-40～85	OK

2-Channel High-Precision Single-Mode Fiber Array Design
Precision Fusion Splicing of Nufern UHNA7 and G657A2 Heterogeneous Fibers
Extremely Low Insertion Loss (IL ≤ 0.3dB, Typical 0.15dB)
Precise 250μm Channel Spacing
Standard 0° (A0°) Endface Grinding Angle
Compact Quartz Glass Cover Package (10×2.5×2.5mm)

Applications

Silicon Photonic Integrated Circuit (PIC) Chip Coupling
Planar Optical Waveguide Circuit (PLC) Device Packaging
High-Speed Optical Communication Transceiver Module Optical Interconnects
High-Precision Optical Test and Measurement Instruments
Micro/Nano Optical Devices and Waveguide Array Interconnects
