1*16 Equipartition PM Optical splitter ，BOX type,Wavelength is 420~456nm PM Panda fiber With 0.9mm Hytrel White Tube,fiber Length 1m (with connector)， connector FC/APC，

Detail Information

Product Description

Detail Information

Document:

A-1x16,PM Fiber Splitter - ...17.pdf

Operating Wavelength:

420-456 Nm

Polarization Extinction Ratio:

≥12 DB

Return Loss:

≥55 DB

Power Handling:

≤0.3 W

Fiber Length:

1.0±0.1 M

Connector Type:

FC/APC

Highlight:

16-channel PM optical splitter

Panda fiber FC/APC connector

420-456nm wavelength fiber coupler

Product Description

1. Features

Ø Low Insertion Loss

Ø Low Extinction Ratio

Ø Available for Slow Only or Fast Axis App

Ø High Stability and Reliability

1*16 Equipartition PM Optical splitter ，BOX type,Wavelength is 420~456nm PM Panda fiber With 0.9mm Hytrel White Tube,fiber Length 1m (with connector)， connector FC/APC， 0

2. Applications

Ø EDFA

Ø Fiber Optical Instrument

Ø Coherent Communication

Ø Power Monitoring

Ø Fiber Sensor

3. Specifications

Parameters		Unit	PM 1x16
Operating Wavelength		nm	420-456
Typical Excess Loss		nm	≤19
Polarization Extinction Ratio		dB	≥12
Loss Uniformity		dB	≤1.6
Return Loss		dB	≥55
Power Handling		W	≤0.3
Directivity		dB	≥50
Operating Temperature		℃	-5~+65
Storage Temperature		℃	-40～+80
Port Type		/	1x18
Fiber Type		/	Panda fiber
Fiber Length		m	1.0±0.1m, others on request
Connector		/	FC/APC, others on request
Package Dimension	2mm/3mm Loose Tube	mm	120×80×18

The default connector key is aligned to slow axis.

5. Ordering information

Couper	-	XXX	XXX	XXX	XX	XX	-	X	X
		Port NO	Wavelength	Modules type	Fiber Type	Fiber Length		Com connector	Port Connector
PM OS= Coupler		16=1X16	435=420~456nm	PM=120 X120 X18	02=250um fiber	10=1.0m		0=None	0=None
				XX=Customized	09=0.9mm Tube	XX=Customized		1=FC/UPC	1=FC/UPC
					20=2.0mm Tube			2=FC/APC	2=FC/APC
					30=3.0mm Tube			3=SC/UPC	3=SC/UPC
					XX=Customized			4=SC/APC	4=SC/APC
								5=LC/UPC	5=LC/UPC
								6=LC/APC	6=LC/APC
								X=Customized	X=Customized
