6CH DWDM Mux Demux Module C53-C58 G657A1 Fiber SC/UPC Low Insertion Loss Optical Multiplexer Demultiplexer for WDM Telecom Network,C53-C58 DWDM Mux Demux Module
Gracyfiber Dense wavelength-division multiplexing (DWDM) is an optical fiber multiplexing technology that is used to increase the bandwidth of existing fiber networks. Standard DWDM Mux Demux package types include ABS box, LGX box, and 19” 1U rack mount. It involves the process of multiplexing many different wavelength signals onto a single fiber. DWDM will allow the transmission of data: voice, video-IP, ATM, and SONET/SDH respectively, over the optical layer.
| Parameters | MUX | DEMUX | |
|---|---|---|---|
| Center Wavelength (nm) | ITU | ||
| Passband(nm) | ITU±011 | ||
| Operating Wavelength (nm) | C53,C54,C55, C56,C57,C58 | ||
| Fiber Type | G657A1 | ||
| Insertion Loss (dB) | <2.0 | ||
| Isolation (dB) | Adjacent | >28 | |
| Non-adjacent | >40 | ||
| Ripple (dB) | 0.3 | ||
| PDL (dB) | 0.1 | ||
| PMD (ps) | 0.1 | ||
| Return Loss(dB) | >45 | ||
| Directivity (dB) | >50 | ||
| Maximum Optical Power (mw) | 300 | ||
| Operating Temperature (℃) | -5～75 | ||
| Storage Temperature (℃) | -40～85 | ||
| Package Dimension LGX (mm) | 100x80*10 | ||
| Length | 0.9mm tube -1.0m | ||
| Connector | SC/UPC | ||
