32 Channel 100GHz Gaussian DWDM AAWG Module C22 C53 Low Loss SC APC Fiber Optic Multiplexer Demultiplexer ABS Box Type
1. Product Overview
The product is packaged in a 120×80×18 mm ABS box, featuring low insertion loss, high isolation, and good transmission stability. It is suitable for 100G DWDM wavelength division multiplexing systems and optical communication network integration applications.
2. Core Product Features
| Parameters | Unit | 40CH 100G DWDM AAWG Module |
|---|---|---|
| Channel | CH | 40 (C19~C58) |
| Chip type | Gaussian | |
| Operating wavelength | nm | 1500~1570 |
| Channel Spacing | GHz | 100 |
| Channel Pass band | nm | ITU±0.11 |
| Insertion Loss | dB | ≤3.5 |
| Bandwidth@1dB | nm | ≥0.2 |
| Bandwidth@3dB | nm | ≥0.4 |
| Adjacent Isolation | dB | ≥26 |
| Non-adjacent Isolation | dB | ≥30 |
| Non-adjacent Crosstalk | dB | ≥21 |
| Return Loss | dB | ≥40 |
| Directivity | dB | ≥50 |
| Channel Uniformity | dB | ≤1.5 |
| Ripple | dB | ≤1.5 |
| Fiber type | cm | G657A1 of 0.9mm loose tube(含头100±5cm) |
| Connector | SC/APC | |
| Chromatic Dispersion | ps/nm | ±20 |
| Operating Temperature | °C | -5~+65 |
| Packaging dimension | mm | L120*W80*H18 |
3. Applications
