8CH PM Fiber Array, Polarization Maintaining Fiber Array, PMFA, Corning PM630-HP Fiber

8CH PM Fiber Array, Polarization Maintaining Fiber Array, PMFA, Corning PM630-HP Fiber

Detail Information
Product Description
Detail Information
Channel Count:
8
Channel Spacing:
127μm
Polishing Angle:
A8°
Insertion Loss:
≤0.3dB
Highlight:

8CH PM Fiber Array Corning PM630-HP

,

Polarization Maintaining Fiber Array PMFA

,

PM Fiber Array with high performance

Product Description
8CH PM Fiber Array, Polarization Maintaining Fiber Array, PMFA, Corning PM630-HP Fiber
1. Product Overview

This product is an 8-channel PMFA polarization-maintaining fiber array, using Quartz Glass material and Corning PM630-HP polarization-maintaining fiber. The channel spacing is 127μm, and the polishing angle is A8°.

2. Core Product Features
Parameters Unit Spec. Value
Channel / 8 OK
Material / Quartz Glass OK
Channel Spacing μm 127 OK
Polishing Angle Degree A8° OK
Package(L)X(W)X(H) mm 10*2.5*2.5 OK
Insertion Loss dB ≤0.3 　
　
　
　
　
　
　
　
Extinction Ratio dB ≥18 25
　
　
　
　
　
　
　
FA PM Fiber Alignment / OK
Connctor PM Fiber Alignment / OK
Fiber Tube mm 0.9 OK
Tube Color / White OK
Length m 1±0.1 OK
Connector / FC/APC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK
  • 8-channel polarization-maintaining fiber array design
  • 127μm channel spacing
  • A8° polishing angle
  • Insertion loss IL < 0.3dB
  • Extinction ratio ER > 18dB
  • Uses Corning PM630-HP polarization-maintaining fiber
  • FC/APC connector, slow axis key
  • 0.9mm blue loose tube, length including connector 100±10cm

8CH PM Fiber Array, Polarization Maintaining Fiber Array, PMFA, Corning PM630-HP Fiber 0

3. Applications
  • Polarization-maintaining fiber communication systems
  • Optical module and optical device coupling
  • Coherent optical communication systems
  • Fiber optic sensing systems
  • Laser and modulator coupling
  • Laboratory optical path testing and R&D platform
