The 16CH DWDM wavelength division multiplexing/demultiplexing module is suitable for 1525–1565nm C-band optical transmission systems, enabling multi-channel wavelength multiplexing and demultiplexing.

16-channel DWDM architecture, suitable for C-band wavelength multiplexing and demultiplexing.

Operating wavelength range covers 1525–1565nm.

Supports a 1310nm Monitor special port, covering 1260–1360nm.

Center wavelength supports ITU Grid C11–C64, and can also be customized according to customer needs.

Optional 100GHz/200GHz channel spacing, channel passband supports ±0.11nm or ±0.25nm.

Supports G657A1/G657A2/G657B3 or SMF-28 fiber; connectors, fiber length, and package size can be customized.

• DWDM optical transmission systems
• Metropolitan area networks and long-distance fiber optic communication networks
• Multi-wavelength optical signal multiplexing and demultiplexing
• 1310nm Monitor Port Monitoring Applications
• Optical Add-Drop Multiplexing and Wavelength Management Systems
• Telecommunications Equipment, Optical Modules, and Optical Transmission Subsystem Integration
• Fiber Optic Test and Measurement Equipment

We can perform optical performance testing and reliability testing according to customer specifications. Testing items can include key indicators such as insertion loss, channel isolation, 1310nm port insertion loss, return loss, polarization-dependent loss, ripple, directivity, power handling capability, and temperature performance.

Please contact us for product specifications, sample information, or customized 16CH DWDM solutions. Please provide your number of channels, center wavelength, channel spacing, package size, fiber type, connector type, and application requirements. Our engineering team will assist in evaluating and recommending suitable optical design and manufacturing solutions.
