Compact Optical Filter for OADM/DWDM | C-Band 1520-1565nm | 250μm Bare Fiber, No Connector | Ultra-Low Insertion Loss Component

Compact Optical Filter for OADM/DWDM | C-Band 1520-1565nm | 250μm Bare Fiber, No Connector | Ultra-Low Insertion Loss Component

Model Number: 953113720-21
Detail Information
Product Description
Detail Information
Channel Count:
4
Fiber Material:
Quartz Glass
Channel Spacing:
250μm
Insertion Loss:
≤0.3dB
Highlight:

Compact OADM DWDM optical filter

,

C-Band 1520-1565nm fiber filter

,

Ultra-low loss DWDM component

Product Description
Compact Optical Filter for OADM/DWDM | C-Band 1520-1565nm | 250μm Bare Fiber, No Connector | Ultra-Low Insertion Loss Component
Product Description

This 4CH SMFA Fiber Array Assembly is a single-mode fiber array designed for high-precision optical coupling and device packaging applications. It uses Quartz Glass material, has a 4-channel structure, a channel pitch of 250μm, and an FA size of 10*2.5*2.5mm.

Key Features

Compact Optical Filter for OADM/DWDM | C-Band 1520-1565nm | 250μm Bare Fiber, No Connector | Ultra-Low Insertion Loss Component 0

  • 4-Channel Single-Mode Fiber Array Structure
  • Quartz Glass Material
  • Channel Spacing 250μm
  • One end: 0° polished capillary with coating
  • The other end: FC/APC connector
  • Uses Corning SMF-28e Fiber
  • 0.9mm White Loose Tube
  • Standard Length 200±10cm
  • Insertion Loss ≤0.3dB
  • FA Dimensions 10*2.5*2.5mm
  • Supports Number Tube Marking, Defined as SMF-28e-2.0
Applications
  • Optical Chip and Fiber Array Coupling
  • Optical Device Packaging and Alignment
  • Photonic Packaging
  • Fiber Interconnect
  • Optical Communication Test Platform
  • Laboratory Precision Optical Path Connection
