1. Features
Ø Low Insertion loss
Ø High Extinction Ratio
Ø Compact Design
Ø Good Channel-to-channel Uniformity
Ø Wide Operating Wavelength
Ø High Reliability and Stability
2. Applications
Ø Coherent communication
Ø Fiber Optic Gyroscope
Fiber Sensor
3. Specifications
|
Parameters |
Unit |
Value |
|
nm |
1260~1650 |
|
|
Test Wavelength |
nm |
1550 |
|
Insertion Loss |
dB |
≤8.2 |
|
Uniformity |
dB |
≤0.8 |
|
Extinction Ratio |
dB |
≥18 |
|
Return Loss |
dB |
≥50 |
|
Directionality |
dB |
≥50 |
|
Pigtail |
/ |
Input:0.9m blue hytrel tube Output:3.0mm yellow PVC Tube |
|
Input & Output Length |
m |
0.5±0.03 |
|
Connector |
/ |
Input=FC/APC(slow axis work), Output=MPO/APC(male)-(Fast axis work) |
|
Fiber Mark |
/ |
Numbering tube |
|
Package Dimension |
mm |
100×80×10 |
|
Power |
mW |
300 |
|
Operating Temperature |
℃ |
-5~+65 |
|
Storage Temperature |
℃ |
-40～+85 |
|
Fiber Type |
/ |
PM 15-U25D |
