Dual 12CH O Band LWDM Mux Demux LGX Module Low Insertion Loss SMF 28e LC UPC for Optical Transmission Network
The 2×12CH O-Band LWDM Mux & Demux 2-in-1 LGX module integrates dual 12-channel multiplexing and demultiplexing functions, operating wavelengths covering 1260~1360nm, with a center wavelength range of 1269.23~1318.35nm.
| OP | Optical Performance | Test Data | |||||
|---|---|---|---|---|---|---|---|
| CH | Channels | 2*12 | |||||
| OW | Operation Wavelength(nm) | 1260~1360 | |||||
| CW | Center Wavelength(nm) | 1269.23~1318.35 | |||||
| CP | Channel Passband(nm) | ±1.05 | |||||
| IL | Insertion Loss(dB) | Channel | Value | Mux | Demux | ||
| COM→UPG | ≤1.0 | 0.60 | 0.81 | ||||
| COM→1269.23 | ≤3.0 | 0.68 | 2.69 | ||||
| COM→1273.54 | 0.99 | 2.61 | |||||
| COM→1277.89 | 1.08 | 2.48 | |||||
| COM→1282.26 | 1.40 | 2.26 | |||||
| COM→1286.66 | 1.58 | 2.18 | |||||
| COM→1291.10 | 1.78 | 1.90 | |||||
| COM→1295.56 | 1.87 | 1.70 | |||||
| COM→1300.05 | 2.15 | 1.59 | |||||
| COM→1304.58 | 2.34 | 1.42 | |||||
| COM→1309.14 | 2.54 | 1.10 | |||||
| COM→1313.73 | 2.63 | 0.98 | |||||
| COM→1318.35 | 2.65 | 0.80 | |||||
| COM→Monitor | ≤24 | 21.30 | / | ||||
| ≤22 | / | 20.01 | |||||
| IS | Isolation(dB) | Adjacent Channel | ≥25 | ≥25 | |||
| Non-adjacent Channel | ≥35 | ≥35 | |||||
| CR | Channel Ripple(dB) | ≤0.5 | ≤0.5 | ||||
| PDL | Polarization Dependent Loss(dB) | ≤0.3 | ≤0.3 | ||||
| RL | Return Loss(dB) | ≥45 | ≥45 | ||||
| FT | Fiber Type | SMF-28e | |||||
| OT | Operating Temperature(℃) | -20~＋85 | |||||
| ST | Storage Temperature(℃) | -40~＋85 | |||||
| PD | Package Dimension(mm) | 215*190*42 in 484*250*44 | |||||
| CT | Connector Type | LC/UPC | |||||
