Gracyfiber's high-end 2*12 channel O-Band LWDM Mux&Demux 2in1 LGX module features a highly integrated bidirectional multiplexing and demultiplexing design, specifically tailored for high-capacity 5G fronthaul and high-speed optical communication networks.
| OP | Optical Performance | Test Data | |||||
| CH | Channels | 2*12 | |||||
| OW | Operation Wavelength(nm) | 1260~1360 | |||||
| CW | Center Wavelength(nm) | 1269.23~1318.35 | |||||
| CP | Channel Passband(nm) | ±1.05 | |||||
| IL | Insertion Loss(dB) | Channel | Value | Mux | Demux | ||
| COM→UPG | ≤1.0 | 0.60 | 0.81 | ||||
| COM→1269.23 | ≤3.0 | 0.81 | 2.78 | ||||
| COM→1273.54 | 1.00 | 2.59 | |||||
| COM→1277.89 | 1.15 | 2.50 | |||||
| COM→1282.26 | 1.39 | 2.43 | |||||
| COM→1286.66 | 1.63 | 2.23 | |||||
| COM→1291.10 | 1.85 | 2.04 | |||||
| COM→1295.56 | 1.88 | 1.80 | |||||
| COM→1300.05 | 2.21 | 1.47 | |||||
| COM→1304.58 | 2.27 | 1.26 | |||||
| COM→1309.14 | 2.42 | 1.10 | |||||
| COM→1313.73 | 2.55 | 0.93 | |||||
| COM→1318.35 | 2.82 | 0.67 | |||||
| COM→Monitor | ≤24 | 21.30 | / | ||||
| ≤22 | / | 20.01 | |||||
| IS | Isolation(dB) | Adjacent Channel | ≥25 | ≥25 | |||
| Non-adjacent Channel | ≥35 | ≥35 | |||||
| CR | Channel Ripple(dB) | ≤0.5 | ≤0.5 | ||||
| PDL | Polarization Dependent Loss(dB) | ≤0.3 | ≤0.3 | ||||
| RL | Return Loss(dB) | ≥45 | ≥45 | ||||
| FT | Fiber Type | SMF-28e | |||||
| OT | Operating Temperature(℃) | -20~＋85 | |||||
| ST | Storage Temperature(℃) | -40~＋85 | |||||
| PD | Package Dimension(mm) | 215*190*42 in 484*250*44 | |||||
| CT | Connector Type | LC/UPC | |||||
