| Model Number: | 910001704-03-1 |
The 4CH PMFA polarization-maintaining fiber array uses PM1310 Corning polarization-maintaining fiber, with a channel spacing of 127μm, a polishing angle of A15°, and is equipped with FC/APC connectors and 0.9mm red loose tubes.
| Parameters | Unit | Spec. | Value |
|---|---|---|---|
| Channel | / | 4 | OK |
| Material | / | Borofloat® 33 | OK |
| Channel Spacing | μm | 127 | OK |
| Polishing Angle | Degree | A15° | OK |
| Package(L)X(W)X(H) | mm | 10*1*1.5 | OK |
| Insertion Loss | dB | ≤0.3 | |
| Extinction Ratio | dB | ≥18 | 25 |
| FA PM Fiber Alignment | / | PMII | OK |
| Connctor PM Fiber Alignment | / | Slow Axis Alignment Key |
OK |
| Fiber Type | / | PM1310(Corning) | OK |
| Fiber Tube | mm | 0.9 | OK |
| Tube Color | / | Red | OK |
| Length | m | 1±0.1 | OK |
| Connector | / | FC/APC | OK |
| Operating Temperature (℃) | 0～65 | OK | |
| Storage Temperature (℃) | -40～85 | OK | |
