Custom 8CH PMFA Block (10x3.5x1.5mm) | Slow Axis Aligned FC-APC | PM980XP with 0.9mm Blue Tube | Gracyfiber
Product Overview
This product is an 8-channel polarization-maintaining fiber array (PMFA), using quartz glass and PM980XP polarization-maintaining fiber. The channel spacing is 250 μm, and the polishing angle is 0°.
Core Product Features
| Parameters | Unit | Spec. | Value |
|---|---|---|---|
| Channel | / | 8 | OK |
| Material | / | Quartz Glass | OK |
| Channel Spacing | μm | 250 | OK |
| Polishing Angle | Degree | 0° | OK |
| Package(L)X(W)X(H) | mm | 10*3.5*1.5 | OK |
| Insertion Loss | dB | ≤0.3 | |
| Extinction Ratio | dB | ≥18 | 25 |
| FA PM Fiber Alignment | / | PM II | OK |
| Connctor PM Fiber Alignment | / | Slow Axis Alignment Key |
OK |
| Fiber Type | / | PM980XP | OK |
| Fiber Tube | mm | 0.9 | OK |
| Tube Color | / | Blue | OK |
| Length | m | 1±0.1 | OK |
| Connector | / | FC/APC | OK |
| Operating Temperature (℃) | 0～65 | OK | |
| Storage Temperature (℃) | -40～85 | OK | |
8-Channel Array Design
Supports an 8-channel structure with a channel spacing of 250 μm, suitable for multi-channel optical signal coupling and integrated packaging applications.
Low Insertion Loss Performance
Insertion loss IL < 0.3 dB, effectively reducing optical link loss and improving system transmission efficiency and stability.
High Extinction Ratio Polarization Maintaining Performance
Applications
