| Brand Name: | Ultra-High Density 2D Fiber Array - 16 To 1024 Channels |
| Model Number: | Ultra-High Density 2D Fiber Array - 16 To 1024 Channels |
GRACYFIBER’s 2D Fiber Array (FA) represents a cutting-edge optical interface solution engineered to overcome the input/output limitations commonly encountered in AI computing infrastructures as well as high-performance computing (HPC) environments. Unlike conventional linear fiber arrangements, this innovative array adopts a two-dimensional matrix structure, enabling it to achieve unprecedented ultra-high fiber density within a remarkably compact footprint.
| Parameter | Unit | 16-1024 |
|---|---|---|
| Wavelength | nm | 1260–1650 |
| Materials | - | Glass / Ceramic |
| Geometry | - | 2D Matrix |
| Core Pitch | - | 127 μm |
| Core Pitch Tolerance | μm | ±1 |
| Insertion Loss | dB | ≤ 0.8 (typical 0.5) |
| Return Loss | dB | UPC ≥ 40, APC ≥ 50 |
| Fiber Type | - | OM1/OM2/OM3/OM4/OM5/G657A1/A2/B3 or Customized |
| Fiber Coating | μm | 250 μm / 350 μm |
| Fiber Type Length | cm | 100 ± 10 or customized |
| Connector | - | FC / LC / SC / E2000 / MT / MPO / MMC |
| Operation Temperature | °C | -5 to 65 |
| Storage Temperature | °C | -40 to 85 |
(This product has been developed specifically to address the space constraints of Co-Packaged Optics (CPO) and the challenges of high concurrency in light-emitting interconnects.)
Q1: What is the channel range available for the Ultra-High Density 2D Fiber Array?
A1: The Ultra-High Density 2D Fiber Array is available in configurations ranging from 16 to 1024 channels.
Q2: What brand manufactures the Ultra-High Density 2D Fiber Array?
A2: The Ultra-High Density 2D Fiber Array is manufactured under the brand name "Ultra-High Density 2D Fiber Array - 16 To 1024 Channels."
Q3: Where is the Ultra-High Density 2D Fiber Array produced?
A3: This fiber array product is made in China.
Q4: What applications is the Ultra-High Density 2D Fiber Array suitable for?
A4: It is suitable for high-density optical communication systems, data centers, and advanced photonic research requiring multiple fiber channels in a compact form factor.
Q5: Can I customize the number of channels in the Ultra-High Density 2D Fiber Array?
A5: Yes, the product supports customization within the range of 16 to 1024 channels to meet specific project requirements.
